UNICO® SQ Scanning UV-VIS Spectrophotometers

Item #: ASUNICOSQUV

Specifications

Wavelength Range 190 to 1,100 nm
Spectral Bandwidth 4 nm
Monochromator Single beam Littrow type, grating 1200 lines/mm
Wavelength Accuracy ±0.8 nm
Wavelength Repeatability ±0.5 nm
Wavelength Calibration Automatic at Start
Light Source Tungsten Halogen/Deuterium  Lamp
Detector Solid Silicon Photodiode
Photometric Readout 1/4 VGA 320X240 pixels backlit LCD
Photometric Range 0 - 200%T | -0.3 - 3.0A | 0 - 9999C
Photometric Accuracy ±%0.5%T
Zero Drift < 0.002A per hour after warm-up
Baseline Flatness ±0.004A
Stability 0.002A/h at 500 nm
Stray Light < 0.15%T
Scanning Speed Hi, Med., Low. Max. 1000 nm/min
Standard Sample Holder 4-position Cell Holder
Analogue/Digital Output Digital, RS232 Serial, Centronics Parallel
Dimensions (L x W x H) 21.65 x 16.54 x 10.63 In. | 550 x 420 x 270 mm
Weight 44 lb | 20 kg
Shipping Dimensions (Lx W x H) 25.59 x 21.26 x 15.35 In. | 650 x 540 x 390 mm
Shipping Weight 53 lb | 24 kg
Power Requirements 115V/60Hz or 230V/50Hz, switchable
Operating Temperature Room Temperature: 22 ±2°C
Humidity Range Less than 85%
Safety Certificate CE
Warranty 3-Year



Warranty

3-Year Warranty



Molded from a special high density polymer, these cassettes keep specimens safely submerged in liquid and are totally resistant to the chemical action of histological solvents. The efficient flow-through slots maximize fluid exchange and ensure proper drainage. The one-piece integral lid eliminates the need for separate steel lids. The snaplatch and hinge-lock design of the UNISETTE prevent early separation of base and lid and allows for one-hand operation. Lids can be opened and closed as often as necessary and they always relock securely without danger of specimen loss. Large labeling areas are located on two sides of the cassettes. Anterior writing area is at a 35° angle. M506 Series is similar to M505 but specially designed to hold biopsy specimens during the embedding process.



Available in non-cytotoxic, non-metallic colors. Each case contains 3 dispenser boxes of 500 cassettes.

Disclaimer:
Due to recent fluctuations in tariffs, pricing is subject to change without notice.
For the most accurate and up-to-date pricing, please contact us directly for a quote.



177.00
Each
SKU Number Spectrum Price Quantity Add to Cart
SQ2800 UV-VIS 190-1,100 nm
7365.71
Each
SQ Spectrophotometer
UNICO® SQ Scanning UV-VIS Spectrophotometers
Special Order
