X500 Motorized Custom Compound Microscope

Item #: ASX500MCUSTUPRIGHT

Specifications

Optical System NIS60 Infinity Optical System
Main Body Alloy Frame with Metal Housing for drift stability
Integrated Fly Eye Illuminator for Homogenous Illumination
Motorized Coarse (2um) and Fine (.05um) Planetary Focus Design
User Selectable Tension Adjustment and Refocus Stop
Eyetubes Trinocular with 2 position light Selection or Integrated Mirror
Ergonomic Tilting Trinocular Eyetube with 3 position light Selections
Ergonomic Binocular Tilting and Telescoping Feature
Eyepieces 10X (25 mm F.O.V) |  15X (18 mm F.O.V) | 20X (15 mm F.O.V)
Condensers Universal Turett Condenser for Brightfield, Phase and Nomarski DIC
Abbe Condenser with Aperture Diaphragm
Flip Top Condenser for lower power with Aperture Diaphragm
Nosepieces Motorized and Encoded Ball bearing 6 position DIC nosepiece
Illumination Motorized Transmitted LED Array:  LED Tuned to 5600 Daylight White
Status Detection with Feedback
Eco Technology for Auto On\Off with user touch
Illumination
Techniques		 Brightfield, Phase, Darkfield Transmitted Light
Nomarski DIC\Hoffman Modulation Contrast Transmitted Light
Epi-Fluorescence
Epi Fluorescence Epi-fluorescence Illuminator and 6 position Turett (Modular and Optional)
Polarized Light Seamount compensators for Polarized Light Applications
Stages Motorized XY stage with 2 slide Holer  (Optional 4, and 8 slide Stages)
Manual XY Controls for Manual Sample Manipulation
Software Full Control of all Motorized Components and cameras
Scan, map, store and revisit positions
Revisit positions at higher magnifications via Pindrop and auto mag function
Capture, measure and annotate images
Control Microscope and all functionality remotely



PR1MA Roto-Mini Series

PR1MA™ Roto-Mini Series

  • Includes tube holders for common tube sizes, 11 x 1.5 / 0.2 mL (pack of 2), 5 x 10-15 mL (pack of 2), 5 x 5-7 mL (pack of 2), 6 x 50 mL (pack of 1)
  • Plus model available with variable speed control and advanced shaking / mixing modes: Mix (Oscillating), Pause, Rock

The new PR1MA™ Roto-Mini Series of rotating mixers provide a wide range of mixing capabilities. Suitable for an array of laboratory applications including resuspension, protein binding, nucleic acid purification, etc. the mixers include interchangeable tube holders for accommodating all common tube sizes from 0.5 mL to 50 mL. The motion can be adjusted from vertical (end over end) mixing, to horizontal (rolling or hybridization style) mixing.

The Roto-Mini rotator is also available in a "Plus" configuration, providing the following additional features:

Variable speed:

5 to 70 rpm

Mix function:

Rotating in combination w/ oscillations (increased mixing)

Pause function:

Rotating with intermittent "stops" during rotation

Rock function:

Back and forth, gentle rocking motion (see-saw)


The Plus models are also compatible with rocking platform (4.5 x 3 in.), as well as a 96 x 0.2 mL tube/strip/plate holder for mixing PCR vessels in the "Mix" (oscillating) mode.
