SmartDrop™ Nano SpectroPhotometers

Limite Time Promo!
Item #: SMARTDROP

Specifications



Model SmartDrop™ L (NS1000) SmartDrop™ X (NS1010) SmartDrop™ XF (NS1020)
Display 7-inch touch screen 7-inch touch screen 7-inch touch screen
Minimum Sample Size 1.0 µL – 2.0 µL 0.5 µL to 2.0 µL 0.5 µL to 2.0 µL
Path Length 0.5mm 0.2mm, 1.0mm 0.05mm, 0.2mm, 1.0mm
Light Source UV LED Xenon Flash Lamp Xenon Flash Lamp
Detector UV Silicon Photocell 2048 Element Linear Silicon CCD Array 2048 Element Linear Silicon CCD Array
Wavelength 260, 280, & 600nm 200 – 800nm (1nm steps) 200 – 800nm (1nm steps)
Absorbance Range 0.2 – 50 A (10mm equivalent) 0.04 – 90 A (10mm equivalent) 0.04 – 300 A (10mm equivalent)
Absorbance Precision 0.005 A 0.003 A 0.003 A
Lower Limit of Detection dsDNA: 10ng/µL dsDNA: 2ng/µL; BSA: 0.1mg/mL dsDNA: 2ng/µL ; BSA: 0.1mg/mL
Upper Limit of Detection dsDNA: 2,500ng/µL dsDNA: 4,500ng/µL; BSA: 135mg/mL dsDNA: 15,000ng/µL; BSA: 360mg/mL
Detection Time < 6 seconds < 5 seconds < 6 seconds
Communication Ports USB for data export USB for data export USB for data export
Voltage Input DC 24V, 2A DC 24V, 2A DC 24V, 2A
Power 25W 25W 25W
Dimensions (WxDxH) 20.8 x 8.0 x 18.6 cm / 8.2 x 11.0 x 7.3 in. 20.8 x 8.0 x 18.6 cm / 8.2 x 11.0 x 7.3 in. 20.8 x 8.0 x 18.6 cm / 8.2 x 11.0 x 7.3 in.
Weight 3.6 kg / 7.9 lbs 2.8 kg / 6.2 lbs 3.6 kg / 7.9 lbs
Absorbance Range 0.0 – 4.0 A 0.0 – 4.0 A 0.0 – 4.0 A
Absorbance Stability [0,3) ≤ 0.5%, [3,4) ≤ 2% [0,3) ≤ 0.5%, [3,4) ≤ 2% [0,3) ≤ 0.5%, [3,4) ≤ 2%
Absorbance Repeatability [0,3) ≤ 0.5%, [3,4) ≤ 2% [0,3) ≤ 0.5%, [3,4) ≤ 2% [0,3) ≤ 0.5%, [3,4) ≤ 2%
Absorbance Precision [0,2) ≤ 0.005 A, [2,3) ≤ 1%, [3,4) ≤ 2% [0,2) ≤ 0.005 A, [2,3) ≤ 1%, [3,4) ≤ 2% [0,2) ≤ 0.005 A, [2,3) ≤ 1%, [3,4) ≤ 2%
Excitation/Emission N/A N/A 460 ± 20nm / 525-570nm
Sensitivity N/A N/A dsDNA: 0.5pg/µL
Linearity N/A N/A R² ≥ 0.995
Repeatability N/A N/A ≤ 1.5%
Stability N/A N/A ≤ 1.5%
SKU Number Description Wavelength Price Quantity Add to Cart
NS1000 SmartDrop L Spectrophotometer 260, 280, & 600nm
6813.35
Each
NS1010 SmartDrop X UV-Vis Spectrophotometer 200 to 800nm (1nm steps)
12601.42
Each
NS1020 SmartDrop XF UV-Vis Spectrophotometer, Fluorometer 200 to 800nm (1nm steps)
14894.67
Each
NS1020-BRQ-100 Fluorescence DNAQuantification Kit, Broad N/A
220.00
Each
NS1020-BR-100 Broad Range dsDNAQuantification Kit, 100 assays N/A
135.00
Each
NS1020-HSQ-100 Fluorescence DNAQuantification Kit, High N/A
240.00
Each
NS1020-HS-100 High Sensitivity DNA Quantification Kit, 100 assay N/A
135.00
Each
