PR1MA™ 96-Well Half Deep Well Plates

PR1MA™ 96 Half-Deepwell Microplates are high-quality plates designed for high-throughput microbial or cell culture, optimized for use in aerated shaking incubations and growth profiling systems.

Manufactured from pure polystyrene with no additives and sterilized by gamma irradiation, these plates ensure optimal sterility and performance for sensitive cultivation needs.

These half-deepwell plates offer exceptional optical clarity, mixing efficiency, and pellet recovery, making them an ideal choice for biotech, pharmaceutical, and academic laboratories conducting high-throughput screening, growth analysis, and sensitive cultures.

Key Features

• Square wells (8 x 8 mm, 17 mm deep) for space efficiency and consistent mixing
• Recommended working volume of 0.3 mL, with a max of 1.1 mL per well
  Suitable for

• Suitable for
• Suitable for 225 rpm (50 mm orbit) or 300 rpm (25 mm orbit) for high oxygen transfer rates
• Ideal for small-volume cultures (up to 1.1 mL per well)

Available in sterile, single-use boxes of 16, individually wrapped in polyethylene foil for easy handling and contamination prevention.

PR1MA™ Plates for General Cultivation

• General cultivation plates ideal for sensitive microbial or mammalian cell cultures (PR-CR1496-C)
• Compatible with universal clamping systems for secure shaking incubation
• Pyramid bottom design ensures efficient cell pellet collection during centrifugation
• Also available in boxes of 20, 10 plates per sealed bag (PR-CR1496-C10)

PR1MA™ Plates for Growth Profiler Applications

• Standard plate for use in Growth Profiler systems (PR-CR1496-DG)
• Light grey color to minimize optical crosstalk between wells
• Transparent bottom laser-welded, no adhesives used, ensuring optical clarity and assay integrity

PR1MA™ Plates for Niche Photometric Applications

• 96 Plate designed for specialized photometric assays (PR-CR1496-F)
• Transparent bottom laser-welded, no adhesives used, ensuring optical clarity and assay integrity

Specifications


Item #	Plate Description	Plate Height	Wells	Bottom Style	Vol.	Rec. Culture Vol.	Color
PR-CR1496-C	Square half deepwell	22 mm	96 Wells, 17 mm	V-Bottom	105.6 mL	0.3 mL	Clear
PR-CR1496-C10	Square half deepwell, 20/pk, 10 pks/cs	22 mm	96 Wells, 17 mm	V-Bottom	105.6 mL	0.3 mL	Clear
PR-CR1496-DG	Square half deepwell	22 mm	96 Wells, 17 mm	Transparent	105.6 mL	0.3 mL	Grey/White
PR-CR1496-F	Square half deepwell	22 mm	96 Wells, 17 mm	Transparent	105.6 mL	0.3 mL	Black
