PR1MA™ 6-Well Deep Well Plates

PR1MA™ 6-Deepwell Microplates are high-quality, sterile plates specifically engineered for CHO-cell cultivation. Each plate is constructed from pure polystyrene with no additives, making it ideal for sensitive biological applications. Designed to replace 125 mL shake flasks, these plates offer superior mixing, better scalability, and a smaller lab footprint.

Key Features

• Six Deep Wells Per Plate: Each square well measures 34 x 34 mm, is 80 mm deep, and has a slightly rounded bottom to prevent foaming
• Recommended working volume of 25 to 35 mL per well, with a maximum capacity of 82 mL
• Pyramid-shaped well bottom allows for easy and consistent centrifugation, centralizing cell pellets for simplified downstream processing
• Sterilized by gamma irradiation. Plates are non-autoclavable and individually sealed for contamination control
• Optimized for Shaking Incubators: Suitable for orbital shaking at 180 rpm (50 mm orbit) or 225 rpm (25 mm orbit) to ensure efficient oxygen transfer and mixing.
• Specifically developed for long-term cultivation (4+ days) of Chinese Hamster Ovary (CHO) cells, widely used in biopharma production
• Packed in boxes of 4, each plate is individually wrapped in polyethylene foil for easy handling and contamination prevention

Available Lid Options

• Standard Polystyrene Lid (PR-CR1406)
• Barcoded Version (PR-CR1406-B) for sample tracking
• Disposable Low-Evaporation Cover (PR-CR1406-DC)

Low-Evaporation Disposable Cover (PR-CR1406-DC)

Enhance your long-term culture performance with this disposable sandwich-style lid, specifically designed to minimize evaporation during extended incubations.

• Evaporation Control: ~130 uL/well/day at 30°C, 50% humidity
• Air Exchange: 6.5 mL/min per well through 4 mm holes
• Ideal for Extended Cultures: Supports stable growth of CHO cells over 4+ days

Construction

• Rigid frame from medical-grade polystyrene
• ePTFE membrane filter (0.3 uM) laminated with polyester/polyamide fabric
• PEVA rubber seal (FDA-grade closed-cell foam) for a tight fit and secure seal

Upgrade to the PR1MA™ 6-Deepwell Plates for more consistent culture performance, improved lab efficiency, and reduced risk of contamination.

Specifications


Item #	Plate Description	Plate Height	Wells	Bottom Style	Vol.	Rec. Culture Vol.	Color
PR-CR1406	Extra high square deepwell w/ PS lid	85 mm	6 Wells, 80 mm	V-Bottom	492 mL	25 - 35 mL	Clear
PR-CR1406-B	Extra high square deepwell w/ PS lid and barcode	85 mm	6 Wells, 80 mm	V-Bottom	492 mL	25 - 35 mL	Clear
PR-CR1406-DC	Extra high square deepwell w/ dispo. cover, 4 mm holes	85 mm	6 Wells, 80 mm	V-Bottom	600 mL	25 - 35 mL	Clear
