This 8 mm round well U-bottom plate combines 1.6mL working volume with automation friendly design. Sturdy and warp resistant design with ultra-flat surfaces and rigid construction, this plate ideal for high throughput screening, sample collection, compound storage, screening, and combinatorial chemistry applications. It is compatible with stackers, grippers, heater/cooler blocks and other instruments that comply with the ANSI/SLAS 2004-1 (SBS) footprint.


Raised rims on each well help protect from cross contamination, minimize sample loss during storage, and make for enhanced sealing with adhesive films, silicone mats, or heat sealing films. Manufactured of inert, chemically resistant, and exceptionally clear virgin polypropylene, this plate can withstand temperatures down to -80C and centrifugation at up to 4,000 x RCF.


Made from medical grade virgin polypropylene (no mold release agents or regrind); certified RNase, DNase, DNA, and Pyrogen Free.

Specifications


Product Type	Multi Well Plates
Number of Wells	96
Number of Plugs	96
Plug Shape	Round – U
Well Shape Top	Round
Well Shape Bottom	Round – U
Material	USP Class VI Polypropylene
Adhesive Material	None
Color	Natural
Alphanumeric	Molded in
Compliance	ANSI/SBS 6-2012
Surface Treatment	None
Certified	DNase-/RNase-/Pyrogen-Free
Overall Height	43.90 mm
Well Depth	41.90 mm
Overall Length	127.78 mm
Adhesive Thickness	None
Width	85.48 mm
Top Width	80.40 mm
Well Diameter Bottom	7.40 mm
Well Diameter Top	8.50 mm
Top Length	123.60 mm
Well Bottom To Deck	1.30 mm
Max Vol.	1.7 mL
Working Vol.	1.6 mL
Vol. w/ Mat Lid	1.5 mL
Plug Depth	41.90 mm
Plug Diameter	7.40 mm
Autoclavable	121C at 15 psi, 15 min.
Max RCF	4,000 RCF
Temp. Range	-80 to 120ºC
Quantity	5 plt/pk, 10 pks/cs
Case Dimensions	9.5 x 10.75 x 17.5 In. | 241.3 x 273.05 x 444.5 mm
Case Weight	9.1 lb | 4.13 kg
