Home > Equipment > Electrophoresis Systems > Gel Imaging and Documentation Systems > Hoefer® Chemi FX6 and FX9 ChemiFluo Imaging Systems

Hoefer® Chemi FX6 and FX9 ChemiFluo Imaging Systems

Item #: ASHOFRFX6FX9GELDOC

Large Tank Blotter with two cassettes, 20 x 20cm

Designed to optimally transfer very large and difficult proteins.
Reproducible transfer results thanks to the plate electrodes made
of platinum-plated titanium (anode) and stainless steel (cathode).
Efficient cooling system: Water circulation system with alumina
ceramic wall located at the chamber base for effective heat
removal.
Safety lid: asymmetrical configuration of electrical contacts
prevents mismatching of electrodes.

SKU Number	Type	Wavelength	MP of Camera	Grayscale	Trans Size	Price	Quantity	Add to Cart
CHEMI-FX6-UNIT	FX6 Unit	Various	6 mp	65,536	25 x 30 cm	36431.0000 36500.00 Each
CHEMI-FX9-UNIT	FX9 Unit	Various	9 MP	65,536	25 x 30 cm	37951.0000 38000.00 Each
CHEMI-FX9-SYSTEM	FX9 System (Chemi+Gel+RGB)	Various	9 MP	65,536	25 x 30 cm	51020.0000 53059.00 Each
CHEMI-FX9-SYSTEM-NIR	FX9 System (Chemi+Gel+RGB+NIR)	Various	9 MP	65,536	25 x 30 cm	55921.0000 57959.00 Each

Hoefer® Chemi FX6 and FX9 ChemiFluo Imaging Systems

Special Order

Quantity:

Request A Quote

For quote requests, include the specific product number(s) in the message box below. Or for a faster experience, existing customers can log in to your account, add the item(s) to your cart, and click the “Request a Quote” button at the bottom of the page during the checkout process.

Request a Quote

Complementary Content

${loading}

Image Resolution	Chemi FX6: 6 MP \| Chemi FX9: 9 MP
Effective Resolution	Chemi FX6: 18 MP \| Chemi FX9: 27 MP
A/D	16 bit
Greyscale	65,536
Dynamic Range OD	4.8
Quantum efficiency	(@ 425 nm) 73%
Lens (motor driven)	F0.80 or F0.95
Stage	Moving
Filter Wheel	All fluorescence applications (7-position motor driven)
UV Filter	Yes
Use with external PC	Yes
Epi LED White Lights	Yes
Lighting (optional)	HiLED (Red, Blue, Green) HiLED (Red, Infrared) HiLED (Red, Blue, Green, Infrared) HiLED (UV, Far Red) Visible Light Converter Blue Converter Screen Slide-out UV Transilluminator 302 nm (20 x 20 cm) Edge Lighting Unit
Max. Image Area	13.58 x 10.87 or 12.72 x 10.08 In. \| 34.5 x 27.6 or 32.3 x 25.6 cm
Min. Image Area	6.14 x 4.91 or 5.91 x 4.65 In. \| 15.6 x 12.5 or 15 x 11.8 cm
Dimensions (D x W x H)	21.65 x 22.44 x 38.98 In. \| 55 x 57 x 99 cm
Weight	Approx. 99.21 lb \| 45 kg
Power Input	100-240 V

Hoefer® Chemi FX6 and FX9 ChemiFluo Imaging Systems

Specifications

Large Tank Blotter with two cassettes, 20 x 20cm
